Vehicle LCD Monitor Options
Compare Vehicle Camera Monitor Specifications
| Specification | SUP-M043 | SUP-M700 |
|---|---|---|
| Screen size | 4.3-inch | 7-inch |
| Display type | Digital color TFT LCD | Digital color TFT LCD |
| Monitor format | Rear-view mirror monitor | Standing monitor |
| Power input | DC 12V | DC 12V |
| Connector options | RCA / 5-pin | RCA / 5-pin |
| Reversing behavior | Automatic reverse switching | Automatic reverse switching; AV2 priority |
SUP-M700 also lists AV1 for DVD and AV2 for the car camera, with brightness, color and contrast adjustment from the monitor buttons.
How to Choose a Vehicle Camera Monitor
Installation Position
Review dashboard space, mirror position, cab layout and driver viewing angle before choosing the display format and mounting location.
Signal Compatibility
Match the monitor input to the camera output. AHD and CVBS are different signal formats, so compatibility must be confirmed for the proposed camera, monitor and connector combination.
Vehicle Camera Monitor FAQ
What is a vehicle camera monitor?
A vehicle camera monitor is the in-cab display in a vehicle camera system. It presents a compatible rear-view, side-view or other selected camera image for the driver or operator.
Can a vehicle monitor display a rear-view camera?
Yes, when the camera signal, connector, power requirements and monitor compatibility are correctly matched. The complete camera and display configuration should be confirmed before installation.
What size monitor is suitable for a truck camera system?
There is no universal size. Choose according to cab space, driver viewing distance, camera quantity, required image area and the application on the target truck.
What is the difference between AHD and CVBS monitor compatibility?
AHD and CVBS are different video signal formats. The camera output must match a supported monitor input, and the connector and complete signal path must also be confirmed.
Read the practical AHD vs CVBS vehicle camera guide for additional signal-selection context.
Does PAL/NTSC AUTO mean a monitor works with any AHD camera?
No. PAL/NTSC AUTO describes automatic detection of supported timing modes; it does not guarantee support for every AHD signal. Confirm the exact receiving channel, video format, resolution and frame rate, then match power, connector pinout and cabling and test the complete camera-to-monitor assembly.
Use the PAL vs NTSC vehicle camera guide to review timing compatibility separately from AHD/CVBS signal selection.
Can SuperPower customize vehicle camera monitors for OEM projects?
Branding, connector options, product configuration and other project requirements can be discussed. The final scope, model compatibility and production requirements must be confirmed for the specific project.
